7.7.5 DISPLAY OF ACTUAL HIGHVOLTAGE VALUE
Procedure:
1. Press "High-voltage" button 27 for
around 2 seconds. Yellow LED 28
 ashes quickly.
The actual high-voltage value is
shown in the LED display 19 for 5
seconds, the display returns to the
previous display after this time.
The actual value display can be
interrupted also before expiration
of the 5 seconds by pressing a
selection button or turning rotary
controller.
The actual high-voltage value can be displayed during the coating process in LED display19.
