36
EPG-SPRINT X
OPERATING MANUAL
VERSION 06/2014 ORDER NUMBER DOC2329371
7.3.4 BASIC AND FACTORY SETTINGS
The EPG-SPRINT X control unit is factory-con gured for operation with Corona manual
or automatic guns. Consequently, the control unit can be used in a manual system or
PrimaTech automatic system without any further settings being required.
However, if the control unit is used with a Tribo manual or automatic gun, the gun type
must be changed. This change is e ected in the con guration settings.
For all other settings, con gurations and special functions, please refer to the chapter
"Device Con guration".
7.3.3 MANUAL GUN MODE WITH EXTERNAL CONTROL
Application is the recoating of work pieces in an automatic coating system. The recoating
is done with a manual gun, but the powder supply is done by the powder center of the
automatic system. The EPG-SPRINT X must receive a release signal via the remote interface
so that the device may clean and coat. The cleaning function (continuous purging) can also
be controlled externally.
Display on device:
"Automatic gun" LED ashes quickly No release signal is present
"Automatic gun" LED is dark Release signal is present
This operating mode is available starting with software version B200. The function must be
selected speci cally via con guration parameter C26.
