WAGNER EPG-Sprint X Operating Manual

39
EPG-SPRINT X
P_01177
OPERATING MANUAL
VERSION 06/2014 ORDER NUMBER DOC2329371
7.5 AIR HIGH OUTPUT MODE HIGH POWDER OUTPUT
With the EPG-SPRINT X, you can combine the feed and atomizing air to obtain a
higher feed air volume. A high powder volume however still depends on other factors.
The length of the suction hose and the length and diameter of the powder hose also a ect
the maximum powder volume.
7.5.1 COMBINING THE AIR OUTPUTS
A Y piece (Order No. 9990149) is needed to combine the feed and atomizing air.
Attention:
The atomizing air is not available in this mode.
Warning messages 1-3 "Insu cient Feed Air", "Insu cient Dosing Air", "Insu cient
Atomizing Air" are deactivated in this mode.
Y-piece
