WAGNER EPG-Sprint X Operating Manual

99
EPG-SPRINT X
2x
2x
2x
2x
OPERATING MANUAL
VERSION 06/2014 ORDER NUMBER DOC2329371
1 CHANGING PARAMETERS
1. Use selection button to select the parameters required.
The yellow LED lights up.
2 CALLING / CHANGING / SAVING RECIPES 14
1. Select required recipe by pressing the corresponding recipe button.
2. Set new parameters (electrostatic, air volume) (see 1).
3. Press the recipe button required for around 2 seconds until the LED  ashes rapidly.
The recipe is saved with new parameters and can be called up again at any time at
the touch of a button.
3 CALLING / CHANGING / SAVING RECIPES 550
1. Press Additional Recipes button.
2. Set recipe number with rotary controller.
The recipe number is displayed in the LED display.
3. Set new parameters (see 1).
4. Press Additional Recipes button for around 2 seconds.
The changed parameters are saved.
5. The recipe number is shown  ashing in the LED display.
6. Set required recipe number with rotary controller.
(Only necessary if the parameters are to be saved under another recipe number.)
7. Press Additional Recipes button for around 2 seconds.
8. LED display  ashes quickly.
Recipe is saved with new parameters.
Operation of the control unit
2. Set parameter value with rotary controller.
The value set is shown in LED display.
