WAGNER EPG-Sprint X Operating Manual

35
EPG-SPRINT X
OPERATING MANUAL
VERSION 06/2014 ORDER NUMBER DOC2329371
7.3 PREPARATIONS FOR COMMISSIONING
7.3.2 GUN RECOGNITION
The EPG-SPRINT X control unit automatically detects whether a manual or automatic
gun is connected to the control unit (parameter C26 must be set to "OFF"). It does this by
checking whether the trigger switch is activated when it is switched on.
If the trigger switch is pressed, the gun is an automatic one. The powder feed is
switched on and o by a primary controller (CCM 2007; CCM Prima or another original
Wagner device for controlling the EPG-SPRINT X).
If the trigger switch is not pressed, the gun is a manual one. The powder feed is
switched on and o with the gun's manual trigger.
Functional faults!
Do not operate the spray gun's trigger while the control unit is being switched on
and is powering up.
NOTICE
7.3.1 OPERATING MODES
The EPG-SPRINT X supports the following operating modes (starting with software
versionB200):
Manual gun mode (manual system with vibrator control)
Automatic gun mode (remote interface for external control of the module)
Manual gun mode with external control (remote interface with external release
(required for coating and cleaning) and for external control of cleaning function)
In the  rst two listed operating modes, the con guration parameter C26 must be set to
OFF (factory setting). The operating mode is automatically recognized by the control unit
(parameter C26 must be set to "OFF", see Chapter 7.3.2).
