WAGNER EPG-Sprint X Operating Manual

22
EPG-SPRINT X
OPERATING MANUAL
VERSION 06/2014 ORDER NUMBER DOC2329371
3 Display: "Tribo Gun"
Lights up when a Tribo gun is connected and selected
4 Display: "Corona Gun"
Lights up when a Corona gun is connected and selected
5 Push button: recipe for "Surface Parts"
6 Push button: recipe for "Second Coating"
7 Push button: recipe for "Pro les"
8 Push button: recipe for "Double Click"
To access the recipe, press the trigger lever on the spray gun twice in quick
succession and hold it down
9 Display LED: recipe for "Surface Parts"
Lights up green when the recipe for surface part is selected
10 Display LED: recipe for "Second Coating"
Lights up green when the recipe for "Second Coating" is selected
11 Display LED: recipe for "Pro les"
Lights up green when the recipe for pro le part is selected
12 Display LED: recipe for "Double Click"
Lights up green, when the recipe for "Double Click" is selected
13 Display LED: "Fault"
Lights up, when there is a fault on the device
14 Display LED: "Automatic Gun"
Lights up, when an automatic gun is connected
15 Push button: "Standby"
To switch into standby mode
High-voltage and powder feed cannot be activated in this mode
To reactivate normal mode, press the button again
16 Display LED: "Standby"
Lights up when the unit is in standby mode
17 Push button: "Purge"
To activate the injector and the hose rinsing
