WAGNER EPG-Sprint X Operating Manual

24
EPG-SPRINT X
OPERATING MANUAL
VERSION 06/2014 ORDER NUMBER DOC2329371
28 Display LED: "High-voltage"
Lights up yellow. The high-voltage is selected and can be adjusted using rotary
controller 24
29 Push button: "Current Limitation"
To activate the function, the current limitation is set with rotary controller 24 and
is indicated in LED display 19
Adjusting range: 5-120 µA
Resolution: 1 µA
30 Display LED: "Current Limitation"
Lights up yellow. The current limitation is selected and can be adjusted using
rotary controller 24
31 Push button: "Characteristic Slope"
To switch the characteristic slope
Display with LED 32
32 Display LED: "Characteristic Slope"
Lights up green
Lower LED characteristic curve,  at
Middle LED characteristic curve, medium
Upper LED characteristic curve, steep
33 Illuminated display: "Powder Quantity"
Lights up green
Display range: 0-100%
Resolution: 3.33%
Single LED display: Set point (high-voltage and powder are deactivated)
Bar display: Actual value (high-voltage and powder are activated)
34 Illuminated display: "Total Air Volume"
Lights up green
Display range: 1-6 m³/h
Resolution: 0.2-0.5 m³/h
Single LED display: Set point (high-voltage and powder are deactivated)
Bar display: Actual value (high-voltage and powder are activated)
35 Illuminated display: "Atomizing, Ionizing and Tribo Air Volume"
Lights up green
Display range: 0.1-4 m³/h
Resolution: 0.1-1.0 m³/h
Single LED display: Set point (high-voltage and powder are deactivated)
Bar display: Actual value (high-voltage and powder are activated)
