53
EPG-SPRINT X
OPERATING MANUAL
VERSION 06/2014 ORDER NUMBER DOC2329371
Properties of the characteristic curve Field of application/remarks
Standard level (black) for poorly rechargeable types of powder
Open-circuit voltage 100 kV for high powder application
Maximum current 120 µA for high application e ectiveness
(Current limitation at 120 µA) This setting corresponds to the usual
Wagner high-voltage modules and
control units.
Medium level (gray)
for small surfaces
Open-circuit voltage 100 kV for types of powder that recharge well
Maximum current 120 µA for metallic powder
to reduce the e ects of overcoating such
as craters and orange peel
Increasing the open-circuit voltage
allows for a greater distance between
the spray gun and the work piece while
maintaining su cient powder charging.
Soft level (white)
for types of powder that recharge well
Open-circuit voltage 100 kV for small powder application
Maximum current 80 µA for post-coatings
