18
PEA-C4XL-S
OPERATING MANUAL
VERSION 03/2014 ORDER NUMBER DOC2345334
Dimensions:
Length/width/height see Chapter 5.3.1
Weight
Electrical:
Input voltage maximum 22 Vpp
Input current maximum 0.9 A
Frequency 19 - 30 kHz
Output voltage maximum 100 kV DC
Polarity negative
Construction type in accordance with DIN EN 50177
types A-P
Protection class IP 54
Pneumatic:
Input air pressure (atomizing air volume) maximum 3 bar; 0.3 MPa, 43.51 psi
Powder output quantity maximum 450 g/min;
maximum 0.99 lbs/min
Ambient conditions:
Operating temperature range 5 - 45 °C; 41 - 113 °F
Relative humidity < 75 %
5.3 TECHNICAL DATA
Outgoing air containing oil!
Risk of poisoning if inhaled.
Provide compressed air free from oil and water (Quality
Standard 3.5.2 according to ISO 8573.1) 3.5.2 = 5 μm / +7 °C;
44.6 °F / 0.1 mg/m³.
WARNING
Ambient conditions:
If low-melting powders are used, the ambient temperature may have to be lower than
30 °C; 86 °F.
Volume measures:
for volumes speci ed in Nm³ (standard cubic meters). One cubic meter of a gas at 0 °C and
1.013 bar is called norm cubic meter.
