WA90 C4 angle adapter
Order No. Designation
1 1 390931 WA90 C4 angle adapter
2 1 390947 WA C4 ET union nut
3
1 390933 WA90 C4 ET nozzle insert
4 1 390942 WA90 C4 ET elbow  tting
5 1 390932 WA C4 ET connecting element
6 1 390946 WA C4 ET locking sleeve
7 1 390945 WA C4 ET threaded sleeve
Wearing parts
Not part of the standard equipment but available as a special accessory
Only available as a set
13.4 WA90 C4 ANGLE ADAPTER

WAGNER PEA-C4XL-S Specifications

General

Brand	WAGNER
Model	PEA-C4XL-S
Category	Paint Sprayer
Language	English
