57
PEA-C4XL-S
OPERATING MANUAL
VERSION 03/2014 ORDER NUMBER DOC2345334
10.2 DISPOSAL
Do not dispose of used electrical equipment with household
refuse!
In accordance with European Directive 2002/96/EC on the disposal
of used electrical equipment and its implementation in national
law, this product may not be disposed of with the household refuse,
but must be recycled in an environmentally correct manner.
Wagner or one of our dealers will take back your used Wagner waste
electrical or electronic equipment and will dispose of it for you in
an environmentally friendly way. Please contact one of our service
points, one of our representatives or us directly to arrange this.
NOTICE
Procedure:
1. Switch o the high-voltage generation on the control unit, close the compressed air
supply and relieve the system of pressure.
2. Press locking button 1 and carefully remove the gun from supporting tube 2.
3. Disconnect electrical cable 3 from connection I on the spray gun.
4. Disconnect the powder feed hose 4 from connection G on the spray gun.
(For handling of the hose coupling, see Chapter 6.5.)
5. Disconnect the atomizing air hose 5 from connection K on the spray gun.
6. Detach the grounding cable 6 from grounding screw L on the spray gun.
7. Dismount supporting tube 2 on the gun attachment.
