OPERATING MANUAL
VERSION 03/2014 ORDER NUMBER DOC2345334
C4 R electrode holder with nozzles
Order No. Designation
1
1 390917 C4 R electrode holder, complete
2
1 390916 C4 R electrode holder
3 1 390310 Wedge
4 1 390313 De ector cone sleeve
5
1 390207 R20 de ector cone ( 20 mm; 0.79 inch)
6 1 390208 R28 de ector cone ( 28 mm; 1.10 inches)
Wearing parts
Not part of the standard equipment but available as a special accessory
Only available as a set
13.3 C4 R ELECTRODE HOLDER WITH NOZZLES
