WAGNER PEA-C4XL-S User Manual

70
PEA-C4XL-S
P_01625
1
2
3
4
5
6
7
OPERATING MANUAL
VERSION 03/2014 ORDER NUMBER DOC2345334
WA60 C4 angle adapter
Order No. Designation
1 1 390927 WA30 C4 angle adapter
2 1 390947 WA C4 ET union nut
3
1 390935 WA30 C4 ET nozzle insert
4 1 390944 WA30 C4 ET elbow  tting
5 1 390932 WA C4 ET connecting element
6 1 390946 WA C4 ET locking sleeve
7 1 390945 WA C4 ET threaded sleeve
Wearing parts
Not part of the standard equipment but available as a special accessory
Only available as a set
13.6 WA30 C4 ANGLE ADAPTER
