8.6 ASSEMBLING THE ANGLE ADAPTER
The standard Corona spray gun is delivered with a  at spray nozzle. The nozzle can be
changed easily, as described below.
Note:
If changing from the  at spray nozzle to the round spray nozzle with de ector cone,
the depth control must be adjusted.
A WA90 C4, WA 60 C4 or WA30 C4 angle adapter is necessary to perform the change,
as listed in Chapter 12 "Accessories".
Note:
A  at spray nozzle as well as a round spray nozzle can be  tted to the angle adapter.
8.6.1 REMOVING THE NOZZLE AND ELECTRODE HOLDER
Procedure:
1. Unscrew union nut 1 from gun housing 5.
2. Pull  at spray nozzle 2 o electrode holder 3.
3. Carefully remove electrode holder 3 from gun
housing 5.
Note:
Do not damage the electrode holder, when pulling it
out and inserting it.
4. Remove powder residues from the parts
removed and from the spray gun.
