33
PEA-C4XL-S
OPERATING MANUAL
VERSION 03/2014 ORDER NUMBER DOC2345334
7.7 PERFORMING A PAINT CHANGE
In the case of a paint change, powder residues must be thoroughly removed from all
powder-conveying parts. In the following, only the procedure for the powder spray gun
is described.
Note:
During a paint change, the nozzle system does not necessarily have to disassembled.
Procedure:
1. Switch o the powder coating system after an automatic ushing and secure it
against being switched back on.
2. In case no automatic ushing is used, ush the gun manually and remove any powder
residues from it before switching o the system:
- Disconnect the powder hose from the spray gun.
- Blow through the spray gun using the air gun and thus remove any powder
residues.
- Switch o the system and secure against unauthorized reactivation.
3. Before starting to connect the powder hose again, all parts carrying powder must be
thoroughly cleaned.
4. The spray gun is ready for use again.
Dust formation!
Danger of poisoning.
Danger due to escaping dust, contamination of the device and
device components.
Before starting cleaning or other manual work, the high-voltage
must be shut down and locked to prevent it from being switched
back on!
During every paint change, the booth suction system and the
lter cleaning system must remain activated!
WARNING
NOTICE
Paint carry-over!
If the union nut is not screwed on tightly up to the stop position, the paint may smear.
