27
PEA-C4XL-S
OPERATING MANUAL
VERSION 03/2014 ORDER NUMBER DOC2345334
Procedure:
1. Switch o the high-voltage generation on the control unit.
2. Press locking button 1 and move supporting tube 2 away backwards.
3. Connect electrical cable 3 to connection I on the spray gun and to the control unit.
4. Connect the powder feed hose 4 to connection G on the spray gun and to the powder
injector.
The handling of the hose coupling is described in Chapter 6.5.
5. Connect the atomizing air hose 5 to connection K on the spray gun and to the control
unit.
6. Connect the grounding cable 6 to grounding screw L on the spray gun and to the
signal ground.
7. Press locking button 1 and supporting tube 2 forwards on the spray gun housing up
to stop.
The locking button 1 must snap into place in the drilled hole in supporting tube 2.
8. Fasten gun on the gun carrier with a suitable device.
Note:
For connecting and fastening the spray gun use the parts listed in the "Accessories"
chapter.
The distance of the installed spray guns to each other must be at least 300 mm;
11.81 inches for functional reasons!
