WAGNER PEA-C4XL-S User Manual

4
PEA-C4XL-S
OPERATING MANUAL
VERSION 03/2014 ORDER NUMBER DOC2345334
6.7 Grounding 28
6.7.1 Grounding the Powder Coating System 29
7 OPERATION 30
7.1 Training the Operating Sta 30
7.2 Safety Instructions 30
7.3 Switching on the Spray Gun 31
7.4 Switching O the Spray Gun 31
7.5 Switching O the Spray Gun in the Event of Faults or Emergencies 31
7.6 Optimizing the Powder Cloud for Your Coating 32
7.7 Performing a Paint Change 33
7.7.1 Impulse Flushing 34
7.8 Reproducible Setting of the Nozzle Position 35
8 CLEANING AND MAINTENANCE 36
8.1 Cleaning 36
8.1.1 Cleaning Sta 36
8.1.2 Safety Instructions 36
8.1.3 Cleaning Procedures 37
8.2 Maintenance 38
8.2.1 Maintenance Sta 38
8.2.2 Safety Instructions 38
8.2.3 Maintenance Procedures 39
8.2.4 Replacing the Spray Gun 40
8.3 Cleaning the Gun and Dismantling the Flat Spray Nozzle 42
8.4 Replacing the Protective Wedge 43
8.5 Fitting the Round Spray Nozzle 45
8.6 Assembling the Angle Adapter 47
8.6.1 Removing the Nozzle and Electrode Holder 47
8.6.2 Fitting the Angle Adapter 48
8.6.3 Replacement of the Wearing Parts 48
8.7 Assembling the Corona-Star 50
8.8 Corona-Star for Angle Adapter 51
8.8.1 Assembling the Corona-Star 51
9
INSPECTIONS IN ACCORDANCE WITH DIN EN 50177: 201004 52
9.1 Overview of Inspections 53
10 DISASSEMBLY AND DISPOSAL 56
10.1 Disassembly 56
10.2 Disposal 57
11 TROUBLESHOOTING AND RECTIFICATION 58
12 ACCESSORIES 60
12.1 Flat Spray Nozzles 60
12.2 De ector Cone for Round Spray Nozzle 60
12.3 Corona-Star Retro t Set 61
12.4 Corona-Star WA C4 61
12.5 Wedge Tool 62
12.6 Electric Cables and Hoses 62
12.7 Angle Adapter 63
12.8 Powder Measuring Bag 64
Table of Contents

WAGNER PEA-C4XL-S Specifications

General

Brand	WAGNER
Model	PEA-C4XL-S
Category	Paint Sprayer
Language	English
