WAGNER PEA-C4XL-S User Manual

54
PEA-C4XL-S
OPERATING MANUAL
VERSION 03/2014 ORDER NUMBER DOC2345334
Section Type of inspection Requirements Inspection by Type of inspection Inspection
interval
4E ectiveness of grounding
measures
All the system's conductive
elements, such as  oors, walls, ceilings, protective grating,
transport equipment, work
pieces, powder tanks, machines or
construction parts etc. in the spray
area, with the exception of parts
which carry high-voltage during
operation, must be connected
to the grounding system. The
resistance of the  oor may not
exceed 108 Ohm.
SP VI/ME/CI
Visual check of ground
connections, perform
function test on grounding
switch, measurement of
grounding resistors.
weekly
5 Resistance to ground of work
piece's locating point
The resistance to ground of
every work piece's locating point
must not exceed 1 megohm
(measurement voltage must be
500 or 1000 V). The design of the
work piece receiver must ensure that the adapters remain grounded
during coating.
SP ME/CI
Measure resistance to ground
(work piece receiver - ground
potential) max. 1 MOhm @
1000 V.
weekly
6 Further inspections Depending on the design and
functions of the booth, further
inspections may be necessary (see
EN 12981).
according to
the booth
manufacturer's
instructions
according to the cabin
manufacturer's instructions
according
to the cabin
manufacturer's
instructions
Legend:
MA = Manufacturer
EM = Employer
SP = Skilled person
FSE = Fire safety engineer ELC = Electrician
TP = Trained person
FI = Function inspection
ME = Measurement
SI = Standard inspection
VI = Visual inspection
CI = Continuous inspection
TI = Technical inspection
