Fault Cause Remedy
No electrostatics (e.g. no wrap
around or powder adhesion)
Fault in the high-voltage
generator
Contact a Wagner service center
Electrical cable from spray gun
to control unit faulty
Replace the electric cable
Cascade in spray gun faulty Contact a Wagner service center
Poor wrap-around
Back-spray
Insu cient or no grounding See Chapter 6.7 "Grounding"
Powder outlet uneven or
inadequate
Contamination Blow through parts carrying
powder
Powder sintering Clean parts carrying powder
Feed device contaminated See operating manuals for the
related devices connected
Feed air / dosing air ratio
incorrect
Adjust at control module resp.
control unit
Wear on powder injector nozzle Replace worn parts on powder
injector ¹)
Spray pattern is uneven Parts of nozzle system worn Replace worn parts
1.) You will  nd the wearing and spare parts in the powder injector operating manual.
