WAREMA Quatronic dialog User Manual

890362_b•en•21.03.2011
We reserve the right to carry out improvements
32
WAREMA Quatronic dialog
®
Operating instructions
6.2.1 Switching on/off the rain
monitor
 Keep the disp/prog button pressed for approx. 5 seconds.
Wind speed: 8m/s 8m/s 8m/s 8m/s
Time: 10:26:47 Wednesday, 20.11.2008
 The selection menu is displayed:
Select the Wind RunT Timer Sun
settings: Rain Temp Product -->
 Press the  button below the word Rain.
 The Rain monitoring (ON/OFF) menu is displayed.
Rain monitoring OFF OFF OFF OFF
(ON/OFF): CH1 CH2 CH3 CH4
 You can use the  buttons to switch the rain monitor on and off at the indi-
vidual facades (F1 - F4).
 Leave the menu after completing the entries using the disp/prog button.
 This saves the changes you made.
Safety functions
Rain monitor
