WAREMA Quatronic dialog
®
Operating instructions
16 Factory presets
Parameter Unit
Articulated
arm awning
Conservatory/
facade awning
External vene-
tian blind
Roller shutter Pleated blind
Wind
Limit value m/s 08 10 12 OFF OFF
Delay Sec 01 01 05 OFF OFF
Off delay Min 10 10 10 OFF OFF
Wind test On/off Off Off Off Off Off
Run time
Up Min:Sec 1:00 2:00 2:30 2:30 2:30
Down Min:Sec 1:00 2:00 2:30 2:30 2:30
Turn time Sec OFF OFF 0.5 1.0 OFF
Turn mode M/S/T OFF OFF M/S S OFF
Timer switch
Up Mo-Fr Hr:Min OFF OFF OFF OFF OFF
Down Mo-Fr Hr:Min OFF OFF OFF OFF OFF
Down Sa+Su Hr:Min OFF OFF OFF OFF OFF
Down Sa+Su Hr:Min OFF OFF OFF OFF OFF
Sun
Limit value, clouds, up kLux 30 30 15 OFF 30
Limit value, sun, down kLux 50 50 35 OFF 50
On delay Min 5 5 2 OFF 5
Off delay Min 10 10 20 OFF 10
Dawn/dusk
Dusk, down Lux OFF OFF OFF 80
OFF
Dawn, up Lux OFF OFF OFF 30 OFF
Rain monitor
On/off On On Off Off Off
Temperature
Outside limit value, up °C OFF OFF OFF OFF OFF
Outside limit value, down °C OFF OFF OFF OFF OFF
Outside move command/sun control Move/sun Move Move Move Move Move
Inside limit value, up °C OFF OFF OFF OFF OFF
Inside limit value, down °C OFF OFF OFF OFF OFF
Inside move command/sun control Move/sun Move Move Move Move Move
Humidity limit
Limit value, up % H
rel
OFF OFF OFF OFF OFF
Limit value, down % H
rel
OFF OFF OFF OFF OFF
Ice warning
On/off Off Off Off Off Off
Comfort timer
Switch-on Mo-Fr Hr:Min OFF 6:00 6:00 6:00 6:00
Switch-off Mo-Fr Hr:Min OFF OFF OFF OFF OFF
Switch-on Sa+Su Hr:Min OFF 6:00 6:00 6:00 6:00
Switch-off Sa+Su Hr:Min OFF OFF OFF OFF OFF
Manual on/off On/off On On On On On
Reference
