Heating
Heating
Electric heating
The heating system of the machine consists of:
• Threeheatingelementsforheatingthewater
inthedrum.
• Atemperaturesensortodetectthewater
temperatureinthedrum.
• Oneortwoheatingcontactorsforswitch-on/
switch-offoftheheatingelements.
Theheatingelementsandthetemperaturesen-
soraresituatedatthebottomoftheouterdrum
closetotheedge.Theycanbeaccessedfront
thefrontafterthefrontplateisremoved.
Thecontactor(s)is(are)placedintherearcontrol
unit.
Dependingonthesizeofthemachine,thefol-
lowingheatingelementsareavailable:
Machine Heatingelementsize
model (kW)
SU620 3x1,3x1.8,3x2.5
SU630 3x3.3
SU645 3x4.33
SU660 3 x 6
SU677 3x7.66
1
1
Heatingelementand
temperaturesensor
5468
Heatingcontactor
5365
