Detergent compartment
Thecompartmentisdividedintofourforpre-
wash,mainwash,rinseandbleaching-agent/
liquid detergent.
The detergent compartment of the machines
is described in detail in section Detergent
compartment.
Drain valve
This valve is a diaphragm valve that opens and
closes by way of the water pressure. The control
valve is situated next to the water valves.
The drain valve of the machine is described in
detail in section Drain valve.
Drain valve
Detergent compartment
Machine presentation
