Waupaca Paca-Ryde - Travel Cable to Controller Wiring

1726 North Ballard Road, Suite 1 - Appleton, WI 54911 - 920.991.9082
Technical Support 855.804.5774 - Parts@waupacaelevator.com
W E
PTE30186-A
06 DEC 2018
Travel Cable Wires Terminals Travel Cable Wires Terminals
11F 21EZ4
22F 22EZ3
33F 23EZ2
44F 24EZ1
55F 25LD
66F 26LU
7FC 27DZ
8 1A 28 NOT USED
9 2A 29 +24
10 3A 30 -24
11 4A 31 AG1
12 5A 32 AG2
13 6A 33 AG3
14 AC Purple 14 Gauge AUX
15 ESTOP White 14 Gauge NEUT
16 SC Black 14 Gauge LT
17 LITE Green 14 Gauge GRD
18 GATE Shielded Red PHONE
19 EZ6 Shielded White PHONE
20 EZ5
CRUSH
HAZARD
CUTTING
HAZARD
ELECTRIC
HAZARD
FALLING
HAZARD
PINCH
HAZARD
STATIC
HAZARD
ELECTRICITY
TRAVEL CABLE TO
CONTROLLER WIRING
SERIES : 114 , 116
Page 48
