Waupaca Paca-Ryde - Excelevator Semi- Annual General Maintence Chart

1726 North Ballard Road, Suite 1 - Appleton, WI 54911 - 920.991.9082
Technical Support 855.804.5774 - Parts@waupacaelevator.com
PTS70057-C
13 MAR 2018
W E
Serial #
Date Installed Floors Travel Speed Motor Voltage
Owner
ALWAYS DE-ENERGIZE ELECTRICAL CIRCUITS and follow proper tag out procedures during servicing or maintenance of elevator.
SERIES : 114, 116
SEMI-ANNUAL GENERAL
MAINTENANCE CHART
1 2 3 4 5 6 7 8 9 10
1 2 3 4 5 6 7 8 9 10
1 2 3 4 5 6 7 8 9 10
1 2 3 4 5 6 7 8 9 10
1 2 3 4 5 6 7 8 9 10
1 2 3 4 5 6 7 8 9 10
1 2 3 4 5 6 7 8 9 10
USE ONE COLUM N PER VISIT ON EVERY VISIT CHECK THE FOLLOWING:
OVERALL INSP ECTION
See customer and correct all complaints
Inspect machine space equipment and clean when necessary
Ride car, checking for unusual noise or operation
Check condition of car top, pit equipment, clean when necessary
Check for burned out lights and replace
PUM P UNIT
M aintain oil tank at proper level [AW-32]
Check for excessive leaks around valve and pipe connections
Check all electrical connections
Test run checking for excessive noise and vibration
Bleed Jack
JACK
Check plunger for signs of rust and scratches
Check packing gland for leakage
Check pipe rupture valve for leakage
Check wear and leakage of hose/pipe
Check pit bucket and empty
Clean and lubricate rollers
CONTROLLER
Check contacts for excessive burning and clean
Check and test battery device
Check fuses, holders, and replace if necessary
GATE
Check gate operation
Check and clean gate operator & switches
CAR
Check alarm bell system
Check emergency stop switch
Check adjustment of car guide blocks
Check roller wheels/guides
Check hall button contacts, clean if required
Check operation and movement of slack cable/broken rope safety
Check COP lights
Check contacts and switches in car operating panel
Check telephone is functioning
HOISTWAY
Check rail bracket fasteners are secure and lubricate rail
Check ropes for equal tension
Check and clean main guide rails and guide blocks
Check wear and insulation on traveling cable
Check junction box
Check and clean interlocks
Inspect and lubricate ropes ( Nyrosten Ropeoil Compound)
Test Emergency Light
Check slack rope switch and pit switch
Final Limits and Pit Switch
Check Car Top Stop Switch
Date Technician
Maintenance Messages
LUBRICATION
RECOMMENDATIONS:
- Use spray lubricant that
meets and/or exceeds MIL-C-
81309D & MIL-C-16173D.
- Approved elevator rope
lubricant should be applied
sparingly to penetrate but not
drip from the rope.
Page 68
