Waupaca Paca-Ryde - Programs & POT Settings

1726 North Ballard Road, Suite 1 - Appleton, WI 54911 - 920.991.9082
Technical Support 855.804.5774 - Parts@waupacaelevator.com
PTE10115-H
12 FEB 2018
W E
Field Programmable Floor Homing
Floor homing runs the elevator car to a speci c  oor after 30 minutes of idle time.
Enabling Instructions:
• Call unit to lowest landing. (tape reader must be on EZ1 magnet)
• Open gate and pull Emergency-Stop button. (ESTP input must be disengaged)
• While in the car, push and hold COP buttons 1 & 2 (simultaneously) until both illuminate,
then release.
• Immediately push and release the desired homing  oor button while 1 & 2 are
illuminated. (they will time out in 6 seconds)
• Selection will  ash multiple times to acknowledge program accepted.
(Wait a few seconds)
Disabling Instructions
• To disable the homing feature, push and hold buttons 1 & 2 (simultaneously) until they light.
Continue to hold 1 & 2 until the lights go out and release.
Hydraulic Exercise Programming
The hydraulic exercise program runs the elevator every 2 weeks if the elevator is idle. This
program is turned ‘ON” when the elevator is shipped.
Disabling/Enabling the Exercise Program Instructions:
• Call the unit to the second stop. (tape reader must be on EZ2 magnet)
• Open gate and pull the Emergency-Stop button. (ESTP input must
be disengaged)
• While in the car, push and hold the COP buttons 1 & 2 (simultaneously)
until they both illuminate.
• While the buttons 1 & 2 are illuminated (they will time out in 3 seconds)
push 2 to enable the exercise program, or 1 to disable the exercise
program.
CRUSH
HAZARD
CUTTING
HAZARD
CRUSH
HAZARD
CRUSH
HAZARD
CRUSH
HAZARD
CRUSH
HAZARD
ELECTRIC
HAZARD
FALLING
HAZARD
CRUSH
HAZARD
PINCH
HAZARD
ANTI-
STATIC
ALERT
PROGRAM FEATURES
SERIES : 114 , 116
PROGRAMS & POT
SETTINGS
Page 56
