PTE10115-H
12 FEB 2018
W
E
PROGRAM FEATURES CONTINUED
Field Programmed Timer for EMI Time-out Applications
Adjustment Instructions:
• Pot 1 adjusts the timer for the EMIs, turn the pot (rheostat) to t the application:
• Fully counterclockwise is 10 seconds, fully clockwise is 120 seconds.
Field Programmed Car Light Time-out
Adjustment Instructions:
• Pot 2 adjusts the timer for the car lights, turn the pot
(rheostat) to t the application:
• Fully counterclockwise is 5 minutes, fully clockwise is 30 minutes.
Gate Cycle Safety Feature
• To ensure the gate contacts are not welded. At a landing; the door close and gate
contacts must open at least once. If just the gate contacts open the unit will be able to run
just 4 times.
• To return to normal operation open and close both the gate and the hoistway door. Then the
elevator will respond to calls.
• To reset elevator program, the gate switch contact must be broken and recontacted to
resume proper function.
CRUSH
HAZARD
CUTTING
HAZARD
CRUSH
HAZARD
CRUSH
HAZARD
CRUSH
HAZARD
CRUSH
HAZARD
ELECTRIC
HAZARD
FALLING
HAZARD
CRUSH
HAZARD
PINCH
HAZARD
ANTI-
STATIC
ALERT
SERIES : 114 , 116
PROGRAMS & POT
SETTINGS
EMI and Car light
timeout features will
not implement any
changes until a landing
door (Door Circuit) has
been cycled; this may
be any landing door.
Pot 1
(EMI)
Pot 2
(Light)
5 MIN
30 MIN
CAR LIGHT TIMER
(Pot 2)
10 SEC
120 SEC
EMI TIMEOUT TIMER
(Pot 1)
To Next Page
