PTS70009-E
W
E
Series: ALL
31 JULY 2017
Must Have
1. Serial Number of the unit
2. Multimeter
3. Wire Stripper
4. 1/8” Flat Screwdriver
5. Flashlight
6. Wiring Diagram for the unit
Other Suggested Items
1. WEC Pendant
2. Note pad
3. Writing Utensil
4. Fuses
5. Socket set SAE and Metric
6. Wrench Set SAE and Metric
7. Allen Wrenches SAE and Metric
8. Clamp on Ammeter
9. Rags and Oil Dry
Troubleshooting Tips
1. Take notes as you troubleshoot for future reference.
2. Visually inspect component(s).
3. Check for loose wires and broken contacts.
4. Be familiar with your multimeter.
5. When testing fuses take them out of the circuit (failure to do so may result in a false reading).
6. When checking for voltage do not check to ground
For Technical Support Call : 1-855-804-5774
CRUSH
HAZARD
CUTTING
HAZARD
CRUSH
HAZARD
CRUSH
HAZARD
ECO-SYSTEM
HAZARD
ELECTRIC
HAZARD
FALLING
HAZARD
INHALATION
HAZARD
CRUSH
HAZARD
KINK
HAZARD
CRUSH
HAZARD
PINCH
HAZARD
STATIC
HAZARD
ELECTRICITY
Having the following items on hand will make the troubleshooting
process easier and quicker.
TROUBLESHOOTING WITH
TECHNICAL SUPPORT
