Fault: Problem Cause: Action:
Elevator Travels in Slow Speed
Only
PLC count is incorrect Check DZ & EZ magnets and sensors
Pressure relief set too low Adjust pressure relief valve
Excessive tension between mov-
ing parts
Check for binding in the rail, sling or jack
HSV Check that VML coil is magnetized
High Speed Circuit Check that HSV circuit is actuating
Misses Destination Floor PLC not seeing DZ input
Check DZ magnets, tape reader, interface
board, and related wiring
Elevator Stops Short of Top
Floor and Returns to 1st Floor
with Car Lights Blinking
Low oil time out fault
90 seconds
Check oil level and oil temperature
Check for leak in pump assembly, pump to
jack plumbing.
Check HSV
Elevator Travels Down Only
Up contactor not pulling in Check up output on PLC and UP contactor
No incoming power
Check up output on PLC and UP contactor
Check for fuse F13A and PF relay
Elevator Relevels Excessively
Misplaced magnet Check Magnet placement
Leak in hydraulic system
Check for internal or external leaks in valve,
hose and/or jack
Leveling speed adjustment Adjust leveling speed
Interlock Will Not Release
When Car is at Floor
EZ input missing
Check magnet placement, tape reader and
interface board
EMI output missing
Faulty EMI Check interlock and related wiring
Interlock missing alignment Correct alignment isse
TROUBLESHOOTING
SERIES : 114 - 116
