PTE10146-F
30 MAR 2018
W E
Output Description Action
Q0.0 In use lights and run contactor Lights when the car is running
Q0.1 UP Lights when the car is running in the up direction
Q0.2 HSV Lights when the car is running in full speed
Q0.3 DV Lights when the car is running in the down direction
Q0.4 SV Lights when the car is running up
Q0.5 Light Relay
Lights when car is stopped at a  oor and the door is
closed, stays lit for 5 min - 30 min
Q8.0 EMI 1
Lights when the car is at the  rst  oor and EZ 1 input is
on
Q8.1 EMI 2
Lights when the car is at the second  oor and EZ 2
input is on
Q8.2 EMI 3
Lights when the car is at the third  oor and EZ 3 input
is on
Q8.3 EMI 4
Lights when the car is at the fourth  oor and EZ 4 input
is on
Q8.4 EMI 5
Lights when the car is at the  fth  oor and EZ 5 input is
on
Q8.5 EMI 6
Lights when the car is at the sixth  oor and EZ 6 input
is on
Q8.6 DF Indicates Door Fault Condition
Q8.7 SCR Reset On First Scan Resets SCR
Q9.0 First  oor acknowledge light Lights when a  rst  oor call is engaged
Q9.1 Second  oor acknowledge light Lights when a second  oor call is engaged
Q9.2 Third  oor acknowledge light Lights when a third  oor call is engaged
Q9.3 Fourth  oor acknowledge light Lights when a fourth  oor call is engaged
Q9.4 Fifth  oor acknowledge light Lights when a  fth  oor call is engaged
Q9.5 Sixth  oor acknowledge light Lights when the sixth  oor is engaged
Q9.6 Not Used
Q9.7 Not Used
Q10.0 AG1
Lights when car is at a  oor where AG1 is programmed
to open
Q10.1 AG2
Lights when car is at a  oor where AG2 is programmed
to open
Q10.2 AG3
Lights when car is at a  oor where AG3 is programmed
to open
ELECTRIC
HAZ ARD
CRUSH
HAZARD
PINCH
HAZ ARD
STATIC
HAZ ARD
ELECTRICITY
TROUBLESHOOTING PLC
INPUTS / OUTPUTS
SERIES : 114 ,116
