USER MANUAL – WebdynSunPM
Version 2.05
préliminaire
12-24 V power supply terminal block
2 Ethernet ports (LAN 1 and LAN 2)
4 0-10 V or 4-20 mA analog inputs
1 Relay output
Indicators:
• Power: 12-24 V power supply status
• Activity: Product status
• Serial1, Serial2, Serial3:
• Tx: Data sent on the RS485/RS422 serial port
• Rx: Data received on the RS485/RS422 serial port
• WAN: Connection status
Power button
Micro SD card slot
3 Digital inputs (ON-OFF or pulsed S0)
1
2
3
4
5
6
7
8
11
8
7
5
2
13
3
4
6
12
9
10
1
3
