USER MANUAL – WebdynSunPM
Version 2.05
préliminaire
3 RS485/RS422 ports
SIM card holder
Modem SMA antenna connector
USB port (for extension)
RESET button
Supported devices
The WebdynSunPM is compatible with all devices that include one of the supported protocols.
Partial list of the supported protocols:
Inverter protocol
Physical interface
Specifications
SMA-net
RS485/RS422 2 wires
100 max
Modbus TCP
Ethernet
254 max
Modbus RTU
RS485/RS422 2 wires or 4
wires
247 max
Power-One Aurora
RS485/RS422 2 wires
100 max
TIC
USB (cable optional)
1 max
Currently, much inverter equipment runs using Modbus.
The concentrator accepts all Modbus RTU and TCP devices.
Product and accessory references
Product:
References
Descriptions
WG0517-A01
WebdynSunPM (Europe and India)
Accessories:
References
Descriptions
AC1601-01
USB / TIC extension 1 modulated input
