USER MANUAL – WebdynSunPM
Version 2.05
préliminaire
• 38400
• 57600
• 115200
• 230400
• 460800
Data bits
data_bits
Number of data bits:
• 7
• 8
Parity
parity
Serial connection parity:
• None: no parity
• Odd: odd parity
• Even: even parity
Stop bits
stop_bits
Number of stop bits:
• 1
• 2
InterFrame
interframe
The waiting time between 2 frames
exchanged on the serial port. This time
is expressed in ms.
See the explanation in section
“3.1.2.1.3.3 - Serial port configuration“
Forwarded TCP
port
forwarded_port
Forwarded TCP port.
If there is a value in this field, the
concentrator opens a modbusTCP port
on the entered port number.
When modbusTCP devices connect to
this port, all sent requests are directly
forwarded to the modbusRTU bus and
the response is returned to the
connected device using this modbusTCP
port.
This option is used to create a
communication tunnel between
modbusTCP devices and the local
modbusRTU network.
The requests are slotted between the
concentrator’s internal monitoring
requests.
3.2.2.3 Networks
The “Networks” part is used to configure the 2 Ethernet interfaces (LAN1 and LAN2) available
on the concentrator. These Ethernet interfaces make it possible for the concentrator to belong
to 2 different Ethernet networks.(see section 2.4.5: “Ethernet interface”)
