USER MANUAL – WebdynSunPM
Version 2.05
préliminaire
Index
“Action”
code
Display
1
1
Parameter value
2
0
None
3-11
4
Instant value
12
8
Instant value
• Device 2 index configuration:
Index
“Action”
code
Display
1-2
2
Min, max and average values
• CSV data file (edited using Excel):
DEVICEINDEX
1
modbusTCP
WPM00C44F_SunSpec_inverter_SMA_Solar_Inverter_9301_modbusTCP.csv
11
1
3
4
5
6
7
8
9
10
11
12
21/02/05-09:50:00
32
52
5
102
1
0
1
0
0
0
0
21/02/05-10:00:00
35
57
5
108
1
10
0
0
0
0
1
DEVICEINDEX
2
SMANET
WPM00C44F_SMA_Inverter_SMA_WR21TL09.csv
6
1(min)
1(max)
1(avg)
2(min)
2(max
)
2(avg)
21/02/05-09:50:00
16
32
26.00
52
58
51.00
21/02/05-10:00:00
4
6
05:50
102
105
103.00
4.1.4 “ALARM” alarms
Alarms are uploaded in the form of CSV format files compressed to Gzip “.gz” format. They
are uploaded to the “ALARM” directory on FTP type remote servers. No files other than alarm
files are uploaded to the servers and the concentrator will not trigger NTP synchronisation.
The list of alarms that can be generated is:
Alarm
source
Info
Description
GATEWAY
Power ON
Concentrator boot
Power OFF
Concentrator shut down
TIC accessory loss
TIC accessory removed
TIC accessory return
TIC accessory reconnected
IO
Definition file name + Index + Value
The value of an alarm type input has
changed
MODBUS
Definition file name + Index + Value
The value of an alarm type index has
changed
