And the following schedule on the Schedule 2 connection:
The following configuration file is obtained:
SCHEDULE_Params[0]=1|everyday|00:00:00|1440|1
SCHEDULE_Params[1]=2|monday|00:00:00|1440|1
SCHEDULE_Params[2]=3|first|00:00:00|1440|1
SCHEDULE_Params[3]=4|middle|01:00:00|600|2
SCHEDULE_Params[4]=5|last|02:02:00|120|12
SCHEDULE2_Params[0]=1|everyday|00:00:00|1440|1
SCHEDULE2_Params[1]=2|everyday|00:00:00|1440|1
SCHEDULE2_Params[2]=3|everyday|00:00:00|86400|1
The index number is calculated automatically by the concentrator starting with 0. If this file is
modified manually, make sure there are no duplicate index numbers as this would result in
the configuration being rejected. Please note that the index number is separate for
“SCHEDULE_Params” and “SCHEDULE2_Params”.
3.1.2.1.3 “<uid>_daq.csv” file
The “<uid>_daq.ini” file contains the list of devices configured on the concentrator and their
interface configurations.
