Webdyn WebdynSunPM - 1.6 Technical Specifications; 1.6.1 General Specifications

14
USER MANUAL – WebdynSunPM
Version 2.05
préliminaire
AC1601-02
USB / TIC extension 1 non-modulated input
AC1101-01
4-20 mA ambient temperature sensor
AC1101-02
Modbus ambient temperature sensor
AC1102-01
4-20 mA surface temperature sensor
AC1401-01
Class C pyranometer
AC1402-01
3 m pyranometer cable
AC1403-01
20 m pyranometer cable
AC1201-01
Modbus slave 8 ON-OFF inputs / 6 relay outputs
AC1201-02
Modbus slave 16 ON-OFF inputs
AC1301-01
Single phase electricity meter
AC1301-02
Single phase electricity meter with relay
AC1302-01
Three phase electricity meter
AC1302-02
Three phase electricity meter with relay
AC1001-01
Irradiation and temperature sensor & 3m Modbus cable
AC1002-01
Irradiation sensor
Technical Specifications
1.6.1 General specifications
Specifications
Descriptions
Power supply
+12V 700mA (some functions are not
supported on 12V)
or
+24V 350mA
Battery
650mAh 3.7V, Lithium-polymer
Consumption
P: 5 W
Pmax: 10W
Dimensions
155x 106 x 58mm
9 DIN rail modules
Box
RoHS compliant
DIN EN 60715 TH35
DIN VDE 0470-1
DIN 43880 size 1
