o Parameters: 1. A wait of 1ms is applied between 2 frames.
o Category: Inverter.
o Model: WR21TL09
o DefFIle: WPM00C715_SMA_Inverter_SMA_WR21TL09.csv. The definition file
name that describes the different variables detected on the SMA-Net device.
• modbus ethernet:
o Index: 1. Index for the second modbus device configured on the concentrator
o Interface: 192.93.121.23:502. This value indicates that the device is of the
Ethernet type at IP address 192.93.121.23 using the default port number, i.e.
502.
o Name: ethernet_192.93.121.23_502_126. The name that will be displayed on
the local web pages
o Address: 126. This device responds at the modbus 126 address
o AcqPeriod: 600. The acquisition period is set to 600 seconds, or one record
every 10 minutes
o Timeout: 5000. The timeout is set to 5000ms
o SerialNumber: empty. Not applicable
o Parameters: 1. The connection is kept alive.
o Category: Inverter
o Model: Solar_Inverter
o DefFIle:
WPM00C715_SunSpec_inverter_SMA_Solar_Inverter_9301_modbusTCP.csv.
The definition file name that describes the different variables configured for
this device detected using SunSpec
When editing this file using Excel, the following display is shown using the CSV format:
If the file is modified using “Excel” type spreadsheet software, the format may be
modified and the “;” delimiters replaced by “,”, making it unusable by the
concentrator. Always make sure to indicate the delimiter format when saving.
3.1.2.1.4 “_sci.ini” file
The “_sci.ini” file contains the list of scripts configured on the concentrator.
The file name is defined as follows: Take the device uid as explained previously and suffix
“_sci.ini” to it. Thus, in the previous example, the generated file name will be
“WPM00BDE4_scl.ini”.
