There are 4 devices in this example:
• An “IO” type device corresponding to the concentrator inputs/outputs
• A “TIC” type “Linky” type device
• A modbus SMA device on serial bus
• A modbus SMA device on Ethernet
Explanation of the different devices:
• IO:
o Index: IO. The IO value indicates that the device is of the “IO” type.
o Interface: empty. As the inputs/outputs are built into the box, this field is
ignored.
o Name : Io. The name that will be displayed on the local web pages
o Address: empty. This information does not concern inputs/outputs
o AcqPeriod: The acquisition period is set to 36000 seconds, or one record every
10 hours
o Timeout: empty. This information does not concern inputs/outputs
o SerialNumber: empty. This information does not concern inputs/outputs
o Parameters: empty. This information does not concern inputs/outputs
o Category: WebdynSunPM
o Model: ioSunPM
o DefFIle: WPM00C715_IO.csv. The definition file name that describes the
different configured inputs/outputs
• TIC:
o Index: TIC1. The TIC1 value indicates that the device is of the “TIC” type.
o Interface: empty. As TIC devices use external interfacing equipment supplied
by Webdyn, this field is ignored
o Name: tic. The name that will be displayed on the local web pages
o Address: empty. This information does not concern TIC devices
o AcqPeriod: The acquisition period is set to 600 seconds, or one record every 10
minutes
o Timeout: empty. This information does not concern TIC devices
o SerialNumber: 041676011381.
o Parameters: 9600. Here, the parameter is the communication speed
o Category: Meter. This value is reserved for future TIC device use
o Model: empty. This value is reserved for future TIC device use
o DefFIle: WPM00C715_TIC_LINKY.csv. The definition file name that describes
the different configured inputs/outputs for this concentrator
• SMA-Net:
o Index: 0. Index for the first device configured on the concentrator
o Interface: SERIAL1. Indicates that the device is connected to serial port 1
o Name: serial1_52224. The name that will be displayed on the local web pages
o Address:52224. The SMA-Net address on the SMA bus.
o AcqPeriod: 600. The acquisition period is set to 600 seconds, or one record
every 10 minutes
o Timeout: 0. This parameter is not supported. The default values apply
o SerialNumber: 2000388220.
