USER MANUAL – WebdynSunPM
Version 2.05
préliminaire
The possible values are:
• None: No authentication requested
by the remote server
• PAP: PAP type authentication
requested by the remote server
Below is a modem configuration example:
type;pin;apn;login;password;authentification
MODEM;;m2minternet;;;None
In this example, the PIN code is empty, the APN is set to “m2minternet”, the login and
password are empty and the authentication type is defined as “None”.
When editing this file using Excel, the following display is shown using the CSV format:
If the file is modified using “Excel” type spreadsheet software, the format may be
modified and the “;” delimiters replaced by “,”, making it unusable by the
concentrator. Always make sure to indicate the delimiter format when saving.
3.1.2.1.3.2 Ethernet connection configuration
Ethernet interface configuration is based on the following parameters:
Device type.
The possible values are:
• LAN1: to configure the LAN 1 interface
• LAN2: to configure the LAN 2 interface
LAN1 for the first line
LAN2 for the second line
The local IP address assigned to the Ethernet
interface.
This value has an effect on the local IP address at
which the box can be contacted on the relevant
Ethernet interface.
This field cannot be empty
192.168.1.12 for the first line
192.168.2.12 for the second line
This field contains the subnet mask used jointly
with the configured IP address.
This field cannot be empty
Routing device configuration to use for the
concentrator to be able to communicate with
devices not present on its local network.
IP address for a DNS server the concentrator is to
use to resolve names.
