WEILER E1650 REMIXING TRANSFER VEHICLE
5-37
Maintenance
5
Maintenance Procedures
Machine - 50 Hour Grease
4 Fittings
3
4
4 Fittings
2
2
6
2
Located on left side of conveyor
5
2
Located on right side of conveyor
4
10
6
2
Located on left side of dump hopper
7
2
8
2
12
2
9
4
11
2
11
2
10
4
Located on right side of
storage hopper
6
2
11
2
11
2
Located on left side of
storage hopper
6
2
7
2
1
4
8
2
Item Description Item No.
Axle Pivot - Front . . . . . . . . . . . . . . . . . . . . . . .1
Caster Wheel. . . . . . . . . . . . . . . . . . . . . . . . . . .2
Caster Wheel Axle . . . . . . . . . . . . . . . . . . . . . .3
Discharge Conveyor Pivot - Lower . . . . . . . . .4
Discharge Conveyor Pivot - Upper . . . . . . . . . 5
Discharge Conveyor Swing Cylinders . . . . . . . 6
Elevator Lift Cylinders - Left. . . . . . . . . . . . . .7
Elevator Lift Cylinders - Right . . . . . . . . . . . .8
Elevator Pivot - Left . . . . . . . . . . . . . . . . . . . . .9
Elevator Pivot - Right. . . . . . . . . . . . . . . . . . . .10
Steering Knuckles . . . . . . . . . . . . . . . . . . . . . .11
Windrow Pivot (Optional) . . . . . . . . . . . . . . . .12
