WEILER E1650 REMIXING TRANSFER VEHICLE
2-11
Machine Controls
2
Machine Controls
(30) Ignition Switch
Lower Seat Control Panel
(1) Lights Switch
Activates work lights located near rear of frame and
optional conveyor lights pointing into paver hopper.
(2) Blade Lights Switch (Optional)
Activates forward facing lights to illuminate dump hopper.
(3) Warning Light Switch (Optional)
Center/straight up - on.
1st position CCW - off.
Push up to turn work lights on.
Center to turn headlights on.
Push down to turn lights off.
Push up to turn lights on.
Push down to turn lights off.
Push up to turn warning lights on.
Push down to turn warning lights off.
30
3
2
1
