WEILER E1650 REMIXING TRANSFER VEHICLE
4-4
Transporting
4
Towing/Retrieving Machine
4. Turn park brake release override knob (4) CW until
tight.
5. Insert park brake release handle (5) into park brake
manual pump lever (6). Pump valve until brakes
release. Stow handle in holder.
6. Attach tow vehicle to the machine using a suitable
towing device strong enough to move and stop the
67,000 lb (30,400 kg) machine.
NOTICE: Damage to the pump and motor can result
from rotating without charge flow for lubrication. Bypass
valves are intended for moving a machine or vehicle for
very short distances at very slow speeds. They are not
tow valves.
7. After tow vehicle is securely attached remove wheel chocks. Tow disabled machine to a suitable
area.
8. Securely chock front and rear wheels to prevent machine from moving.
9. Apply park brake by turning park brake release override knob (4) CCW until tight.
10. Detach tow vehicle from disabled machine.
NOTICE: Before placing machine back into service, test the park brakes.
11. Turn each multifunction valve bypass (1) CW until tight (3 turns).
12. Remove wheel chocks.
