56 EN LIFE-BASE
WM 68331 04/2021
4 Assembly
9. With MEDUMAT Standard
2
: Screw 1 cable clamp 105 and
1 protective disk 104 to the spacer plate using 1 screw 101.
When doing so, note: The flat side of the cable clamp faces
down.
10. With MEDUVENT Standard: Screw 1 cable clamp 105 and
1 protective disk 104 to the spacer plate using 1 screw 101.
When doing so, note: The flat side of the cable clamp faces
down.
12 mm
MEDUMAT Standard
2
105
104
101
105
12 mm
MEDUVENT Standard
104
101
