28 EN MEDUVENT Standard
WM 67851 01/2021
3 Description
No. Designation Description
1 Breathing circuit
Administers the inspiratory gas to the patient via a
mask or tracheal tube. There are 2 types of breathing
circuit:
• Reusable breathing circuit (see 3.4.2, p.29)
• Disposable breathing circuit (see 3.4.3, p.31)
2 Hook and loop strap with clip Attaches the breathing circuit to the patient’s clothing.
3 Testing bag Simulates a ventilated patient in the function check.
4 SD card
For reading out session data and service data, and for
performing software updates.
5 Portable unit (example)
Used to transport the device (see “3.6 Transport
options”, page 33).
6 12 V cable
Supplies the device with power from the vehicle's on-
board power supply.
7 Breathing system filter For filtering and humidifying respiratory air.
8 MEDUtrigger Used to trigger mechanical breaths manually.
9 MEDUtrigger connecting cable Connects the MEDUtrigger to the device.
10 Power supply unit and charger Supplies power to the device.
11 EasyLung for WEINMANN Emergency
Simulates a ventilated patient for presentation
purposes and in the function check.
12 Hygiene filter
Protects the device from viral and bacterial
contamination.
13 Pressure reducer
Reduces the pressure of the oxygen from the oxygen
cylinder to the operating pressure for the device.
14 Charging adapter
Connects the power supply unit and charger or the
adapter cable for 12 V on-board power to the device.
15 Ventilation mask Connects the breathing circuit to the patient.
16 Adapter for disposable breathing circuit
Allows the device to be operated with a disposable
breathing circuit.
17 Oxygen inlet tube
Routes the oxygen from the oxygen supply to the
device.
