3 Description
7 Patient valve Switches between inspiration and expiration.
Comprising:
8 Holder for check valve diaphragm
Connects the patient valve to the ventilation hose, and
includes the check valve diaphragm.
9 Check valve diaphragm
The respiratory gas flows through the check valve
diaphragm only toward the patient. No rebreathing
takes place.
10 Main body
Provides a connection for a mask, a tracheal tube or
the elbow.
11 PEEP control diaphragm
In combination with the control cover, creates a
pressure chamber for PEEP control.
12 Control cover
In combination with the PEEP control diaphragm,
creates a
pressure chamber for PEEP control.
13 Measuring circuit (reusable)
Comprising:
14 Pressure measuring tube Measures ventilation pressure at the patient.
15 Flexible oxygen tube Supplies oxygen to the patient.
16 PEEP control tube
The device controls the patient valve and PEEP by way
of the PEEP control tube.
17 Adapter for reusable breathing circuit Connects the measuring circuit to the device.
18 MEDUtrigger connecting cable Connects the MEDUtrigger to the device.
No. Designation Description
