9 Servicing / Cleaning
Training manual Convotherm 4 124
5.
Turn the adjustment gauge over and place it in the position
shown in the illustration.
Make sure that the adjustment gauge now sits flush with the
bottom of the door catch and lies flat against the catch.
6.
Slowly close the appliance door until the catch roller rests
against the tip of the adjustment gauge.
7.
Check the gap between the bottom edge of the
catch roller and the adjustment gauge.
The gap should equal at least 2 mm here.
8.
If this is not the case, undo the two fixing screws on the door
catch unit and move the door catch until the gaps meet the
sizes specified above.
9.
Re-tighten the fixing screws.
Make sure you do not alter the vertical position in the process.
Adjusting the door gap on table-top units: Hinge side
1.
Close the appliance door.
2.
The door gap needs to be checked at the top and bottom of the
appliance on the hinge side.
