9 Servicing / Cleaning
Training manual Convotherm 4 126
Distance for door contact switch adjustment
1.
Open the appliance door.
2.
Attach the adjustment gauge for table-top units to the door as
shown in the illustration.
3.
Close the door as far as the adjustment gauge allows.
4.
This now gives the defined gap for adjusting the
door contact switch.
See the Training manual.
Door flush with top of appliance for table-top units
1.
Close the appliance door.
2.
Place the adjustment gauge in the position shown in the illustra-
tion.
3.
Check that the door is flush on both the left and right sideas
shown in the illustration.
The difference in height must not exceed 2mm.
