9 Servicing / Cleaning
Training manual Convotherm 4 127
Adjustment gauge for adjusting floor-standing units
Item Function
1
Tightening the temperature sensor
2
Vertical catch offset
3
Gap between door and front section
4
Safety thermostat reset
5
Door gap on hinge side
6
Catch height
7 Door flush with top of appliance
(Not shown: tool laid flat on top cover of appliance)
Requirements
Check that the following requirements have been met:
 The appliance has cooled down.
 The appliance has been disconnected from the power supply and protective measures taken to
ensure the power cannot be switched on again.
