- ii -
WHIRLPOOL CORPORATION assumes no responsibility for any repairs
made on our products by anyone other than In-Home Service Professionals.
FORWARD
This Whirlpool Job Aid, “2008 24" Front-Loading Automatic Washer” (Part No. 8178738), pro-
vides the In-Home Service Professional with information on the installation, operation, and ser-
vice of the 2008 24" Front-Loading Automatic Washer. For specific information on the model
being serviced, refer to the “Use and Care Guide,” or “Tech Sheet” provided with the washer.
The Wiring Diagram used in this Job Aid is typical and should be used for training purposes only.
Always use the Wiring Diagram supplied with the product when servicing the unit.
GOALS AND OBJECTIVES
The goal of this Job Aid is to provide information that will enable the In-Home Service Pro-
fessional to properly diagnose malfunctions and repair the 2008 24" Front-Loading Automatic
Washer.
The objectives of this Job Aid are to:
Understand and follow proper safety precautions.•
Successfully troubleshoot and diagnose malfunctions.•
Successfully perform necessary repairs.•
Successfully return the washer to its proper operational status.•
Copyright © 2008, Whirlpool Corporation, Benton Harbor, MI 49022

Whirlpool WFC7500VW0 Specifications

General

Style	Front-Loading
Color	White
Washer Capacity	2.3 cu ft
Dryer Capactity	-
Max Spin Speed	1200 RPM
Spin Speeds	2
Spin Class	B
Number of Cycles	11
Cycle Selections	Spin + Drain
Wash	Silk
Options	-
Hours	-
Noise level	-
Temperature Selections	Tap Cold (All Cold Rinses)
Energy Class	-
Annual Energy Consumption	64 kWh
Annual Water Consumption	-
Water Consumption Per Cycle	-
Voltage	120V
Frequency	60Hz
Current	15 A

Weight and Dimensions

Depth	33 1/2 in
Height	33 1/2 in
Width	23 1/2 in
Net Weight	-
