4-5
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
1. Unplug washer or disconnect power.
2. Turn off the water supply to the washer.
3. Remove the front cover from the washer
(see page 4-9 for the procedure).
REMOVING THE PRESSURE SWITCH
4. Press and release the two wire connec-
tor locking arms and pull the connectors
off the pressure switch.
5. Pull the pressure hose off the pressure
switch fitting.
6. Unsnap the pressure switch off the pres-
sure switch holder, then remove the
switch from the washer.
Pressure Hose
Wire Connectors
Pressure Switch
Pressure Switch
Pressure Switch
Holder
To Next Page
